Ground Based Guardrail

Ground Based Barrier Systems

Additional Photos

KEE KLAMP

Kee Klamp® fittings are recognised as a mainstay in the construction of tubular structures such as ground based barriers and guardrails. The versatility and flexibility of the fittings have been proven over the past 80 years in thousands of global applications.

Kee Klamp® fittings offer a versatile solution for barrier, handrail and guardrail construction. Systems are iron castings manufactured to the requirements of BS EN 1562 & 1563.

  • Quick and easy construction of ground based barrier solutions
  • No welding or hot works permits required
  • No special tools required
  • Flexible system can accommodate site variations and be used for multiple applications
  • Available off the shelf
  • Cost effective solution
  • Effective alternative to welding

EASE OF INSTALLATION

Kee Klamp® systems simply join standard sizes of structural steel tube (17.5mm O/D to 60.3mm O/D) into virtually any required configuration using a wide range of fittings. Fitting are TÜV certified for strength and can support an axial load of 900 kg with a safety factor of 2:1.

Kee Klamp® fittings are hot dip galvanised and feature KEE KOAT corrosion protected grub screws and THREDKOAT recess protection for guaranteed durability. Designed with ease of installation in mind, Kee Klamp® fittings eliminate the need to weld or fabricate and offer a high level of safety.

SETTING GROUND BASED SAFETY STANDARDS

Kee Klamp® fittings are manufactured to meet current standards

  • BS EN ISO 1461
  • Meet specified loadings up to 1500 Nm
  • TÜV certified for strength
