Pallet Safety Gates

The KEE GATE range of pallet safety gates has been designed to allow employers to work safely when moving goods onto a mezzanine floor or other raised working surfaces.

• Complies with the requirements of 14122-3
• Available in Galvanised steel or Aluminium
• Constructed from Kee Klamp® and Kee Lite® fittings which are TUV approved components for quality assurance
• Damage can be quickly and easily repaired as there are no welding
• Cycle tested for 50,000 openings for guaranteed durability
• Salt spray tested for corrosion resistance to ensure continuous operation, even in corrosive environments
• Minimal number of moving parts means lower maintenance
• Supplied part assembled for ease of on-site installation

EASE OF INSTALLATION

The pallet gate range is designed to fit seamlessly into an existing guardrail or barrier where opening protection is required.

Available in 4 models, the range is fully adjustable in width and can accommodate openings up to 1.8m. Kee Gate® pallet gates are modular in design and are constructed from Kee Klamp® and Kee Lite® fittings. Should the pallet safety gate be damaged in any way, individual fittings can be quickly and easily replaced, reducing operational downtime.

PALLET SAFETY GATE MODELS

Kee Gate® pallet gates are balanced for a positive open and close action and are available in 4 different configurations to accommodate different operational requirements.

Type A – Standard Pallet Gate

Accepts pallets up to 1.4m x 1.48m with a maximum capacity of 1.6m

Type B – Narrow Pallet Gate

Accepts pallets up to 1.4m x 1.48m with a maximum height capacity of 1.8m

The gate’s design requires less floor space to load and unload, making it ideal for use on mezzanines which have limited space. A toe-board is mounted on the mezzanine edge side.

Type C – Tall Pallet Gate

Accepts pallets up to 1.4m x 1.48m with a maximum height capacity of 2.2m

The Tall Pallet Gate offers the tallest capacity of the range. The cantileve

r design provides maximum height but with minimal ceiling height requirements. A toe-board is mounted onto the mezzanine edge side.

Type D – Premium Wide Pallet Gate

Accepts pallets up to 1.4m x 1.95m with a maximum height capacity of 1.6m

The Premium Wide Pallet Gate offers the widest load capacity of the range and provides workers with a head clearance of 2m. Made from aluminium with toe-boards mounted on all sides to protect the gate from pallet contact.

SETTING SAFETY GATE STANDARDS

The Kee Gate® range of pallet gates are have been tested and comply with the following:

• EN14122 Part 3
• Life cycle testing to BS6325-2 Clause 6.5 – Opening and closing of the hinge mechanism
• Salt spray testing to ASTM B117-11-55 over 200 hours to assess performance of coating to resist corrosion
